EPOXY 325

Concrete COATING

Tough as nails


This epoxy concrete coating repels chemicals and resists abrasion. Best used as a primer. Available in clear or wide variety of colors.

EPOXY 325

$99.88$449.88

1 Gallon Kit | Clear (Amber): $99.88 | Color: $109.88

2 Gallon Kit | Clear (Amber): $179.88 | Color: $189.88

5 Gallon Kit | Clear (Amber): $389.88 | Color: $399.88

Final Sale

Clear

Description

Tough as nails

This epoxy concrete coating repels chemicals and resists abrasion. Best used as a primer. Available in clear or wide variety of colors.

What it is

Water-based, semi-gloss two-component epoxy floor coating

What it's for

Indoor garage floors, shop floors, warehouses, kennels

What it does

Coats and protects concrete with a tough, chemical resistant semi-gloss finish. You must etch or grind concrete before applying this product

What it's made of

High quality cyclo-aliphatic epoxy resins

Priming done right

A durable, long lasting coating

What's the finish/color

Clear or color, semi-gloss

How do you apply it?

3/8" nap epoxy glide roller

What's so special about it

Used only on indoor applications this product will stop dusting, repel oils/grease, chemicals, acids and resist abrasions. Use the Urethane 645 afterwards as a top coat for complete protection

What else is like it?

Urethane 645: A high gloss urethane top coat applied after the 325

Gallery

Photos and videos of Ghostshield concrete sealers in action

Technical

Technical specs, application instructions, testing data

EPOXY 325 rises above


Epoxy 325 meets or exceeds the following tests:

ASTM D-1308: Chemical Resistance

ASTM D-3363: Film Hardness

ASTM D-4541: Pull-Off Strength

ASTM D-4060: Abrasion Resistance

ASTM D-2794: Impact Resistance

ASTM D-3359: Adhesion

TECHNICAL SPECS

  • Feature: Durable Coating
  • Chemistry: Cycloaliphatic Epoxy
  • Color: Clear (amber), tile red, beige, medium gray, light gray, off white, white
  • Finish: Semi-gloss
  • Category: Coating
  • Carrier: Water
  • Availability: 2 component kit
  • Packaging: 1 Gallon Kit, 2 Gallon Kit, 5 Gallon Kit
  • Coverage: 200 sq. ft. per gallon at 5-7 mils wet film thickness
  • Interior/Exterior: Interior
  • Application Method: Roller/brush
  • Application Temperature: 55-90 degrees F with relative humidity below 75%
  • Number of Coats: 1
  • New Concrete: Yes, at least 28 days after being poured
  • Storage/Shelf Life: 1 Year
  • Clean up: PM Solvent
  • VOC Content: 175 g/L
  • Film Thickness: 5-7 mils, (2-3 mils dry)
  • Impact Resistance: 50 in/lb
  • Abrasion Resistance: 54 mg
  • Adhesion: 425 psi
  • Viscosity: 700 cps
  • Primer: None

CURE TIMES 70ºF

  • Pot Life – 1 gallon volume: 1 – 1.5 hours
  • Tack Free (dry to touch): 5-8 hours
  • Recoat or Topcoat: 7-10 hours
  • Light Foot Traffic: 16-24 hours
  • Full Cure (Heavy Traffic): 2-7 days

CHEMICAL RESISTANCE

  • 10% Sodium Hydroxide: Long Term Splash Spill
  • 10% Sulfuric: Short Term Splash Spill
  • 10% Hydrochloric Acid: Short Term Splash Spill
  • 20% Nitric Acid: Not recommended
  • 50% Sodium Hydroxide: Short Term Splash Spill
  • Acetic Acid 5%: Short Term Splash Spill
  • Ethylene Glycol: Long Term Immersion
  • Gasoline: Short Term Splash Spill
  • Mek: Not Recommeded
  • Xylene: Short Term Splash Spill

PREPARATION

  1. The concrete substrate to be coated must be clean, dry, and completely free of loose particles, grease, oil, or any substance that would interfere with proper bond.
  2. Surface and air temperatures must be at least 55°F during application. Surface and air temperatures should not exceed 90°F. Keep material from freezing.
  3. The surface-zone moisture content of the concrete should not exceed 4% wt. A test should be made to determine that the concrete has an appropriate vapor barrier. This can be done by placing a 4’X4’ plastic sheet on the substrate and taping down the edges. If after 24 hours, the substrate is still dry below the plastic sheet, then the substrate does not show signs of eventual hydrostatic pressure problems that may later cause disbanding.
  4. For a one or two coat thin build system (3-10 mils dry) we recommend either mechanical scarification or acid etching until a suitable profile is achieved. For a complete system build higher than 10 mils dry, we recommend a fine brush blast (shot blast). If acid is used to clean the concrete, neutralize the surface completely and rinse it with water prior to application. Then wait for the concrete to dry out for at least 24-48 hours.

APPLICATION

Mixing:

This product comes pre-packaged by weight. Kits should be mixed in their entirety. Epoxy 325 A and Epoxy 325 B should be thoroughly mixed before combining. Scrape the bottom and sides of each container. Epoxy 325 A and Epoxy 325 B can then be combined (Epoxy 325 is sold as a pre-packaged kit and Epoxy 325 Part A should be mixed in its entirety with Epoxy 325 Part B). After the two parts are combined, mix well with slow speed mixing equipment such as a jiffy mixer until the material is thoroughly mixed and streak free. This product is an emulsion product and should be mixed well before using.

Application:

Test the sealer in an inconspicuous area to ensure the desired coverage and appearance is achieved. The mixed material can be applied by brush or roller. Workable time is about 1 hour. Maintain temperatures within the recommended ranges during the application and curing process. Apply material with relative humidity within the parameters. When the end of the pot life has been reached, you will find that the material becomes hard to apply and will actually tend to roll back up onto the roller. Do not try to continue application when the coating has reached this step. Applications made at different times with differing environmental conditions, may show slight variations in gloss. Coverage is approximately 200 sq. ft. per gallon. Make sure you test the surface for dryness prior to use and allow at least 8 hours before walking. A full cure will take up to 7 days to complete.

Recoating/Topcoating:

If you opt to recoat or topcoat this product, you must first be sure that all of the solvents and water have evaporated from the coating during the curing process. However, it is best to test the coating before recoating or topcoating. This can be done by pressing on the coating with your thumb to verify that no fingerprint impression is left. If no impression is created, then the recoat or topcoat can be started. Always remember that colder temperatures will require more cure time for the product before recoating or topcoating can commence. Before recoating or topcoating, check the coating to insure no epoxy blushes were developed (a whitish, greasy film or deglossing). If a blush is present, it must be removed prior to topcoating or recoating. A standard type detergent cleaner can be used to remove any blush. Many epoxy overlays and coatings as well as urethanes are compatible for use as a topcoat for this product as well as multiple coats of this product.

NOTES

  • Restrict the use of the floor to light traffic and non-harsh chemicals until the coating is fully cured. It is best to let the floor remain dry for the full cure cycle. Dependent on actual complete system application, surface may be slippery, especially when wet or contaminated; keep surface clean and dry.
  • Some cleaners may affect the color of the floor installed. Test each cleaner in a small area, utilizing your cleaning technique. If no ill effects are noted, you can continue to clean with the product and process tested.
  • The clear is not water clear (it is an amber clear) and is not suitable for topcoating over previously color coated floors. The clear is suitable as a primer or concrete sealer only.
  • Color or gloss may be affected by humidity, low temperatures, chemical exposure or sodium vapor lighting.
  • Product will yellow in the presence of UV light.
  • For best results use a 1/4” or 3/8” nap roller.
  • Slab on grade requires moisture barrier.
  • Substrate temperature must be 5°F above dew point.
  • All new concrete must be cured for at least 28 days.
  • Product color will vary from batch to batch. Use only product from the same batch for an entire job.
  • Improper mixing or too thick of an application may result in product failure.
  • Light or bright colors (white, etc.) may require multiple coats or a topcoat to achieve a satisfactory hide, depending on the substrate.
  • For added chemical resistance, color stability or UV stability, topcoat with Urethane 645.

Clean Up

Clean equipment, tools and surfaces with PM solvent. Unused or old material may be disposed of in a waste disposal site in accordance with local, state and federal laws.

Precautions/Safety

Use appropriate safety equipment during application and handling. Please refer to the safety data sheet (SDS) for additional precautionary instructions before use.

Best Performance

  • Proper application is the responsibility of the user.
  • Make sure the most current versions of technical data sheets and safety data sheets are being used.
  • Keep out of reach of children and pets.
  • Store in a cool, dry place away from direct sunlight. Avoid opened containers, as moisture will cure the material.

Coverage

200 square feet per gallon. Variations in texture and porosity of substrate will affect the coverage and performance of the product.
